Fixed Security Camera

Hanwha TNM-C3620TDR Bi-spectrum AI Radiometric Camera QVGA thermal / 2MP visible

Hanwha TNM-C3620TDR Bi-spectrum AI Radiometric Camera QVGA thermal / 2MP visible

  • Camera Type: Wisenet T Series Bi-spectrum AI Radiometric Camera
  • Thermal Imaging:
    • 320 × 240 uncooled thermal sensor @ 30 fps
    • <50 mK NETD
    • Built-in 4.7 mm thermal fixed lens (HFoV: 50°)
  • Visible Imaging:
    • 2MP visible sensor @ 30 fps
    • Built-in 4 mm fixed lens (HFoV: 87.6°)
    • 150 dB WDR
  • Video Compression: Triple codec support – H.265, H.264, MJPEG
    Bandwidth Optimization: WiseStream II and AI-based WiseStream III
  • AI Analytics (Visible):
    • Object classification: Person, Face
    • Detection types: Virtual line (crossing/direction), virtual area (loitering, intrusion, enter/exit), motion detection, audio detection, appear/disappear
  • Radiometric Features:
    • Temperature monitoring across full FoV or up to 6 user-defined quadrangle ROIs
    • Detection range: –20°C to 130°C (–4°F to 266°F)
  • Alarm Events:
    • Actions: Email/FTP image upload, alarm output, PTZ preset handover, edge/NAS recording, HTTP/HTTPS/TCP notifications, audio playback, MQTT publication
  • Cybersecurity: FIPS 140-2, Level 2 compliant
  • Edge Storage: 1× Micro SD slot (up to 256 GB)
  • Power Input: PoE+ or 12V DC
  • Compliance Note: This product is subject to the Thermal Agreement
  • Order Note: Special order; non-cancellable and non-returnable

This product must have the necessary documentation prior to leaving the boundaries of the United States. See more here.

$7,600.00 USD
$7,600.00 USD $7,600.00 USD
Sale Sold out
Shipping calculated at checkout.

SKU: TNM-C3620TDR
View full details

Product Information

Hanwha TNM-C3620TDR Bi-spectrum AI Radiometric Camera QVGA thermal / 2MP visible

The Hanwha TNM-C3620TDR Bi-spectrum AI Radiometric Camera (SKU: TNM-C3620TDR) combines QVGA thermal imaging and 2MP visible light in a single powerful solution for comprehensive situational awareness and temperature monitoring. With its dual-sensor design, it provides synchronized thermal and optical views for enhanced detection, verification, and analysis in a wide range of environments, including industrial, utility, and perimeter security applications.

The thermal sensor offers radiometric capabilities, allowing for precise temperature measurement and real-time alerts based on user-defined thresholds—ideal for proactive equipment monitoring and fire prevention. Integrated AI analytics enable reliable detection of humans and vehicles, significantly reducing false alarms and improving operational efficiency. The visible channel captures full HD color video for clear identification and visual confirmation. Additional features include H.265/H.264/MJPEG compression with WiseStream II, bi-directional audio, SDXC edge storage (up to 256GB), and flexible power input options (PoE+, 12V DC, 24V AC). Housed in a rugged IP66, NEMA 4X, IK10-rated enclosure, the TNM-C3620TDR is built for dependable performance in any environment.

Dual-Spectrum Imaging for Complete Situational Awareness

The Hanwha TNM-C3620TDR combines a QVGA (320 x 240) thermal sensor with a 2MP visible light camera, delivering synchronized thermal and optical views in a single device. This bi-spectrum design enables operators to detect heat anomalies while visually verifying incidents, enhancing security, fire detection, and equipment monitoring across industrial and critical infrastructure environments.

AI-Enhanced Object Detection for Smarter Security

With onboard AI-based analytics, the TNM-C3620TDR can accurately detect and classify humans and vehicles in the visible channel, reducing false alarms and enabling faster, more intelligent threat response. AI detection improves perimeter protection by filtering out irrelevant motion such as animals, debris, or foliage.

Radiometric Temperature Monitoring with Alarm Triggers

The thermal sensor supports radiometric analysis, offering real-time temperature data with pixel-level accuracy and customizable threshold alarms. This allows early detection of overheating equipment, fire hazards, or unsafe conditions—ideal for preventive maintenance and operational safety in high-risk areas.

Built for Harsh Environments with Smart Streaming

Encased in a durable IP66/IP67, IK10, and NEMA 4X-rated housing, the TNM-C3620TDR is designed for reliable operation in extreme weather and industrial conditions. It supports triple codec streaming (H.265, H.264, MJPEG) with WiseStream II & III, SD card storage, alarm I/O, and audio—ensuring seamless integration into modern security and SCADA systems.

Digital Downloads

Product Specifications and Downloads

Documentation

Export Restrictions

The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
