Fixed Security Camera

Hanwha TNM-C4942TDR Bi-spectrum AI Radiometric Camera VGA thermal / 4K visible

Hanwha TNM-C4942TDR Bi-spectrum AI Radiometric Camera VGA thermal / 4K visible

  • Camera Type: Wisenet T Series Bi-spectrum AI Radiometric Camera
  • Imaging Type: VGA thermal / 4K visible dual sensor
  • Thermal Imaging:
    • 640 × 480 (VGA) uncooled thermal sensor @ 8 fps
    • <60 mK NETD
    • Built-in 9.1 mm fixed lens (HFoV: 50°)
    • Radiometric temperature detection across entire FoV or up to 10 user-defined quadrangle ROIs
    • Temperature detection range: –20°C to 130°C (–4°F to 266°F)
    • AI object detection: Person, Vehicle with BestShot support
    • AI thermal analytics: Object detection, virtual line (crossing/direction), virtual area (loitering, intrusion, enter/exit), motion detection, temperature detection
  • Visible Imaging:
    • 4K visible sensor @ 30 fps
    • Built-in 4.4–9.3 mm motorized varifocal lens (HFoV: 112.1°–47.5°)
    • WDR 120 dB
    • IR illumination range: up to 30 m (98 ft)
    • AI object detection: Person, Face, Vehicle (car, bus, truck, motorcycle, bicycle), License Plate with BestShot
    • AI visible analytics: Virtual line, virtual area, motion detection, tampering, defocus detection, appear/disappear, audio detection, sound classification, shock detection
  • Video Compression: Triple codec – H.265, H.264, MJPEG
  • Bandwidth Optimization: WiseStream II (thermal) and WiseStream III (visible, AI-based)
  • Alarm Events:
    • Image upload (email/FTP), email notifications
    • Edge/NAS recording, alarm outputs, PTZ preset handover
    • HTTP/HTTPS/TCP messaging, audio clip playback, MQTT publication
  • Cybersecurity: FIPS 140-2, Level 2 compliant
  • Edge Storage: Dual microSD card slots (up to 512 GB each)
  • Power Input: PoE+ or 12V DC
  • Protection Rating: IP66/IP67, IK10, NEMA 4X, NEMA TS 2 (2.2.8, 2.2.9)
  • Export Compliance: Thermal cameras with frame rates under 9 fps do not require end user export documentation
  • Order Note: Special order; non-cancellable and non-returnable

This product must have the necessary documentation prior to leaving the boundaries of the United States. See more here.

$11,450.00 USD
$11,450.00 USD $11,450.00 USD
Sale Sold out
Shipping calculated at checkout.

SKU: TNM-C4942TDR
View full details

Product Information

Hanwha TNM-C4942TDR Bi-spectrum AI Radiometric Camera VGA thermal / 4K visible

The Hanwha TNM-C4942TDR Bi-spectrum AI Radiometric Camera (SKU: TNM-C4942TDR) combines advanced VGA thermal imaging with ultra-high-definition 4K visible video in a single, intelligent surveillance platform. Engineered for industrial safety, perimeter security, and infrastructure protection, it offers simultaneous thermal and optical views to ensure reliable detection and verification under any lighting or weather conditions.

With built-in radiometric capabilities, the thermal sensor accurately measures temperature variations across the scene and enables user-defined threshold alerts—ideal for fire risk prevention, equipment monitoring, and proactive maintenance. The 4K visible camera provides crisp, detailed imagery for enhanced scene awareness. AI-powered analytics improve efficiency by classifying humans and vehicles, reducing false alarms and streamlining event response. The TNM-C4942TDR supports H.265/H.264/MJPEG compression with WiseStream II, bi-directional audio, SDXC edge storage (up to 256GB), and flexible power options (PoE+, 12V DC, 24V AC). Housed in a rugged IP66, NEMA 4X, IK10-rated enclosure, it is built to perform in the toughest outdoor environments.

Dual-Spectrum Imaging for Comprehensive Surveillance

The Hanwha TNM-C4942TDR combines a VGA (640 x 480) thermal sensor with a 4K visible camera, offering bi-spectrum imaging to enhance detection and verification capabilities. The thermal sensor detects heat anomalies in low-visibility or challenging environments, while the 4K visible camera provides detailed visual confirmation, making it ideal for critical infrastructure, industrial safety, and high-security monitoring.

AI-Enhanced Object Detection for Smarter Response

Equipped with AI-powered analytics, this camera automatically detects and classifies humans and vehicles in the visible spectrum, significantly reducing false alarms from non-critical movements like foliage or animals. The real-time threat detection and automated responses are essential for large-scale security operations, perimeter defense, and safety monitoring in dynamic environments.

Radiometric Thermal Imaging for Precise Temperature Monitoring

The TNM-C4942TDR supports radiometric temperature measurement, providing pixel-level thermal data for accurate heat detection and temperature threshold alerts. Whether used for fire prevention, overheating equipment detection, or environmental hazard monitoring, it ensures early intervention before problems escalate in sectors such as energy, manufacturing, and transportation.

Robust, Weather-Resistant Design with Seamless Integration

With its IP66, IK10, and NEMA 4X-rated housing, the camera is designed for outdoor use in harsh conditions. It supports H.265, H.264, MJPEG, and WiseStream II compression, along with edge storage (up to 256GB), two-way audio, and alarm I/O. This flexibility allows for easy integration into VMS platforms and SCADA systems, ensuring a scalable solution for any security infrastructure.

Digital Downloads

Product Specifications and Downloads

Documentation

Export Restrictions

The information contained in this page pertains to products that may be subject to the International Traffic in Arms Regulations (ITAR) (22 C.F.R. Sections 120-130) or the Export Administration Regulations (EAR) (15 C.F.R. Sections 730-774) depending upon specifications for the final product; jurisdiction and classification will be provided upon request.
